Conveyor Belt Hot plate hydraulic vulcanizer
The line of Conveyor Belt vulcanizing presses rubber machine are of high automation level and compact advanced structure, suitable to vulcanize giant conveyer belt such as nylon conveyer belt, common conveyer belt, anti-fire conveyer belt, wire rope conveyer belt etc.
II. Technical parameter
| Total Pressure (T ) | 7000 |
| Platen Size(mm) | 2000X10000X100 |
| Working layer: | 2 |
| Daylight gap (mm) | 300 |
| Plate Unit Area Pressure(MPa) | 3.5 |
| Piston Diamterter (mm) | φ600 |
| Piston Stroke (mm) | 600 |
| Max working temperature (° C) | 170 |
| Max Steam Pressure (Mpa) | 0.6 |
| Cylinder Quantity( set/unit) | 16 |
| Heating type: | steam heating |
| Control type: | PLC automatic control |
| Overall Dimension (L X W X H)(MM) | 2800X10800X4500 |
